FCARD Intelligent Temperature Measurement Screening System
Highly sensitive infrared detectors are used for monitoring and rapid temperature measurement and screening of “high-temperature individuals” in floating populations


产品介绍

Infrared body temperature detection area


1.Recognition and temperature measurement can be completed in 0.3 seconds


2.Support query records by cloud system


3.Support OEM software, customize LOGO and make installation package (large quantity)


Functions:


1.Highly sensitive infrared detectors are used for monitoring and rapid temperature measurement and screening of “high-temperature individuals” in floating populations.


2.Adopt high-precision black body adjustment to accurately capture each heating element.


3.Can capture accurate face technology in on second among many people, which can simultaneously detect


4.RGB camera, accurately locate abnormal body temperature appearance, automatic sound alarm when encountering abnormal body temperature, save abnormal person’s appearance picture.


5.Support HDMI high-definition video output port, 10 inches to 100 inches television as a screen (with voice output at the same time)


6.Easy to install, no need for professional construction, just plug in the power, and HDMI can be used to connect to the television.


产品参数

AI Temperature Measurement Unit


Communication Interface: USB interface x1, network port x1


Data Transmission: RJ45 cable, 100/1000Mbps self-appetite TCP/IP protocol


Working Voltage: DC12±10% 2A


Power: 15W(MAX)


Video output: HDMI2.0


Appearance Material: metal shell


Video Connection Number: 1 channel dual optical video


Capture Rate: 99.9%


Recognition rate: 98%


Processing Speed: 10 people/second


Whitelist Capacity: 80,000pcs


Visible Light Pixels: 2 million, 1/2.8 inches target surface


Visible Light Frame Rate: PAL: 1080p@25fps    NTSC: 1080p@30fps


Minimum Illumination: 0.0001  Lux (F1.2, AGC ON), full color night vision


Lens Interface Type: C/CS


Protection Level: static surge level 3B


Working Temperature: -10℃ ~ 65℃


Temperature Measurement Range: 0℃ ~ 50℃


Measurement Accuracy: ±0.3℃


系统功能

常用功能

专业功能

全新功能

Applications:


1.Government Agency  Service Hall/Licensing Office/Bank


2.Office    School    Factory/Science Park/Gymnasium


3.Transportation       Station/Port/Airport/Car
